TP-LINK (ER706W-4G) Omada 4G+ Cat6 Dual Band AX3000 VPN Router, 6x GB Ports, Omada Mesh, High-Security VPN

TP-LINK (ER706W-4G) Omada 4G+ Cat6 Dual Band AX3000 VPN Router, 6x GB Ports, Omada Mesh, High-Security VPN

Omada 4G+ Cat6 AX3000 Gigabit VPN Router


• Support 4G+ Cat6: Insert a Nano SIM card to enjoy up to 300 Mbps.
• AX3000 Dual-Band WiFi 6: Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
• 6 Gigabit Ethernet Ports: Provide high-speed wired connectivity.
• 5 High-Gain Detachable Antennas: Extend and concentrate the Wi-Fi signals.
• Centralized Management: Cloud access and the Omada app for easy management.
• Omada Mesh: Seamlessly connects to EAPs that support mesh technology.
• High-Security VPN: Supports IPSec / SSL / WireGuard / OpenVPN / PPTP / L2TP VPN.

Specifications:
- #Hide#Wireless Standard : Wi-Fi 6/6E (802.11ax)
- Max Single Band Wi-Fi Rate : 2402 Mbps
- Security : Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise Access Control: Source/Destination IP Based Access Control Filtering: Web Group Filtering URL Filtering Web Security ARP Inspection: Sending GARP Packets ARP Scanning IP-MAC Binding Attack Defense: TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN
- Port/NAT Forwarding : 66 Byte Packet forwarding rate:1,453,489 pps / 1,453,488 pps 1,518 Byte Packet forwarding rate: 81274 pps / 91275 pps
- Button(s) : Reset Button
- Power Supply : 12VDC / 2A Power Adapter Max Power Consumption: 17.3W
- Wireless Features : Seamless Roaming Mesh (with EAP that supports Mesh) OFDMA Beamforming MU-MIMO Rate Limit: Based on SSID/Client Airtime Fairness Multiple SSIDs: 16 in total (8 per radio) Guest Network
- VPN Support : IPsec VPN : 100 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec Failover IKE v1/v2 MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) PPTP VPN : PPTP VPN Server PPTP VPN Client (10) 50 Tunnels PPTP with MPPE Encryption
- Package Contents : ER706W-4G Power Adapter Quick Installation Guide
- Wi-Fi Rating : AX3000
- Signal Rate : 5GHz: Up to 2402Mbps 2.4GHz: Up to 574Mbps (HE160) 4G Frequency: Downlink: 300 Mbps; Uplink: 50 Mbps
- Interface(s) : 1 x Gigabit SFP WAN/LAN Port 1 x Gigabit WAN Port 4 x Gigabit LAN/WAN Ports 1 x Nano SIM Card Slot
- Antenna(s) : Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas LTE: Two 4.0dBi omnidirectional detachable antennas
- Warranty : Limited Lifetime
- #Hide#Mesh Wi-Fi Support : Yes (Mesh Wi-Fi)1
- Dimensions : (WxDxH )226 x 131 x 35 mm) (Antenna dimensions are not included)
- Management : Omada App Centralized Management Cloud Access Zero-Touch Provisioning Maintenance: Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3 Diagnostics (Ping & Traceroute) NTP Synchronize Port Mirroring CLI (Standalone Mode) Syslog Support Management Features: Automatic Device Discovery Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule Captive Portal Configuration
- DHCP : DHCP Server DHCPv6 PD Server (only in Standalone Mode) DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces Multi-Net DHCP
- Dynamic DNS : Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization
- . : NAT: One-to-One NAT Multi-Net NAT Virtual Server Port Triggering NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP
- Package Type : Retail
- Bands : Dual Band
- Type : 4G Router
- Max Wired Transfer Rate : 10/100/1000 Mbps
- Connectivity : Wireless
- Frequency : 2.4GHz and 5GHz
- Additional Features : ACL: IP/Port/Protocol/Domain Name Filtering Advanced Routing: Static Routing Policy Routing RIP OSPF Bandwidth Control: IP-Based Bandwidth Control Load Balance: Intelligent Load Balance Application Optimized Routing Link Backup(Timing, Failover) Online Detection Session Limit: IP-Based Session Limit
- Environment : Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing
- Package Weight : 1.5500 kg
