Description

Cooler Master MasterFrame 500 Mesh ARGB Modular Open-Frame ATX Case w/ Glass Side, 3x ARGB Fans, FreeForm 2.0 Exo-Structure, USB-C 20Gbps, Black

Premium modular ATX case - MasterFrame 500 Mesh

Premium open-frame ATX case designed for modular builds, extreme cooling, and total customization through the FreeForm 2.0 platform.



MasterFrame 500 Mesh
The MasterFrame 500 Mesh is a premium open-frame mid-tower chassis built for high-performance components, advanced cooling setups, and limitless customization. Embracing the FreeForm 2.0 design philosophy, it supports ATX to E-ATX motherboards and provides full access to modular design files. With enhanced mesh panels for improved airflow, it empowers builders, modders, and creators to push the boundaries of PC design.




FreeForm 2.0 Exo-structure
The exposed frame structure enhances chassis adaptability and provides flexible configuration options for various scenarios.





Versatile & Maker-Driven
Its open source design and interchangeable panels offer endless personalization possibilities, transforming your chassis into a unique expression of style.




Flexible Motherboard Support
Supports Mini-ITX to E-ATX motherboards, offering compatibility with a wide range of builds and configurations.




Extensive Cooling Support
Can house up to eight fans and multiple radiator sizes (up to 360mm), ensuring superior thermal performance.





Ample GPU Clearance
Accommodates graphics cards up to 390mm, offering plenty of space for high-end GPUs.





Tool-Free Panel Removal
Easily remove side panels and other components without tools for quick access and modifications during build or upgrades.





Included GPU support bracket
The included GPU support bracket prevents GPU sag and ensures stability during intense gaming or high-performance workloads, maintaining a clean and secure build.





Specifications:
- Weight/Dimensions : (LxWxH) 471 x 261 x 544 mm (Incl. Protrusions) (LxWxH) 471 x 261 x 531 mm (Excl. Protrusions) Volume (incl. Protrusions): 60.9 L
- #Hide#Window(s) : Yes (Window)
- Additional Features : FreeForm 2.0 Exo-Structure for Flexible Configuration Options GPU Support Bracket included Tool-Free Panel Removal See Overview for more details
- Compatibility : GPU Clearance: 390 mm CPU Clearance: 190 mm PSU Clearance: 235 mm Cable Routing (Behind MB Tray): 43 mm
- Package Weight : 15.2000 kg
- Drive Bays : 1 (Bottom) x 2.5" / 3.5" Drive Bays (or SSD) 1 x Preinstalled 3.5" / 2.5" Drive Bay (or SSD)
- Expansion Slots : 8 Expansion Slots
- Motherboard Support : Mini-ITX, Mini-DTX, Micro-ATX, ATX , E-ATX*, SSI-CEB* (*Conditional Support)
- #Hide#Max Radiator Support : 360mm
- Warranty : 2 Years
- #Hide#LED Lighting : Yes (LED Lighting)
- #Hide#Small Form Factor : No
- Material : Exterior: SGCC Steel, Aluminium Side Panel (Right / Left): Tempered Glass
- Power Supply Wattage : No PSU
- . : Radiator Support: Front: Up to 360 mm Top: Up to 360 mm Rear: 120 mm
- Colour : Black
- Cooling System : Included: Front: 2 x 200mm SickleFlow 200 ARGB PWM Fans Rear: 1 x 120mm ARGB PWM Fan Fan Mounts: Front: 3 x 120 / 2 x 140 / 2 x 180 / 2 x 200 mm Top: 3 x 120 / 2 x 140 / 2 x 180 / 2 x 200 mm Rear: 1 x 120 mm Bottom: 3 x 120 / 3 x 140 mm
- Form Factor : ATX
- Connectors / Controls : 1 x USB 3.2 Gen 2x2 Type C 2 x USB 3.2 Gen 1 Type A 1 x 3.5mm Headset Jack (Audio+Mic)
